Progressive Die Stamping

1、Process Introduction | What problems can stamping solve?

High speed mass production: progressive die 200-800 times/min, single shift daily production of 100000-500000 pieces, cost 60-80% lower than machining
Complex three-dimensional shape: a combination of multiple workstations including deep drawing, punching, flanging, and shaping, achieving box body, shell, flange, and reinforcement ribs
High precision dimensions: Precision progressive die ± 0.01 mm, hole position accuracy ≤ 0.02 mm, direct assembly without secondary processing
Excellent surface: Cold rolled sheet surface Ra ≤ 0.8 µ m, galvanized/coated sheet can still maintain its original appearance after stamping
Material saving: Closed material layout, material utilization rate ≥ 85%, suitable for precious metals and stainless steel thin materials

2、Capabilities

Item	Specification
Maximum Press Capacity	25 t – 800 t Mechanical / 1250 t Servo
Maximum Die Size	2500 × 1200 mm (Progressive Die)
Material Thickness	0.05 mm – 12 mm (Steel) / 0.1 mm – 8 mm (Stainless Steel) / 0.1 mm – 10 mm (Aluminum)
Blanking Accuracy	±0.01 mm / Hole Pitch ±0.02 mm
Feeding Method	Servo Roller Feeding, Step Accuracy ±0.005 mm
Batch Capacity	1 – 1,000,000 pieces/batch, Die Change < 15 min (Quick Clamping System)

3、Our Equipment

AIDA NC1-800 (800 t)

Workbench 2500 × 1200 mm, servo speed regulation 20-120 SPM
Suitable for deep drawing of large automotive coverings and forming of high-strength steel

AIDA NC1-200 (200 t) x 3 units

800 × 800 mm, progressive die high-speed 200-600 SPM
Precision punching, material cutting, motor iron core, connector spring plate dedicated

Bruderer BSTA 125 (125 t)

Swiss high-speed punch, 1250 SPM, ± 0.005 mm step distance
0.1mm stainless steel electronic connector with multi station progressive design

Yamada Dobby 60 t x 6 units

600 SPM， Carrying the top material and tapping unit inside the mold
Small precision parts, M1-M3 in mold tapping completed in one go

Hyson servo press 125 t

Arbitrary travel curve, pressure fitting force closed-loop ± 1%, suitable for precision forming+online detection

4、Stamping Case Studies | Stamping Cases

Case 1 | New Energy Motor Core

Material: 0.35 mm non oriented silicon steel coil

Shape: Outer diameter 180 mm, 72 slots, thickness 40 mm, stacked rivet

Process: Progressive mold at 72 stations+rotating stacking riveting+online burr detection ≤ 0.02 mm

Result: Flatness ≤ 0.05 mm, iron loss ≤ 2.4 W/kg, monthly production of 1.2 million pieces

Case 2 | Car door hinge

Material: B340LA high-strength steel 4mm

Shape: 3D deep drawing+side punching, 3D tolerance ± 0.1 mm

Process: 800 ton servo press+three-axis transfer arm, 7-station transfer mold

Result: The positional accuracy of the side hole is 0.08 mm, no machining is required, and the annual production capacity is 800000 sets

Case 3 | 5G RF shielding cover

Material: 0.2 mm C7521 phosphor bronze

Shape: 128 pieces consisting of 0.25mm micro louvers and 0.3mm convex bulges

Process: 125 ton high-speed punch, step distance of 12 mm, 600 SPM

Result: The louvers have no burrs, the shielding effectiveness is>100 dB, and the monthly production is 5 million pieces

5、 Mold and Automation

Self designed progressive/transfer/composite molds, MaxProgress simulation forming, reducing trial molds by 40%
Mold steel: SKD11, CD53, hard alloy inserts, with a lifespan of ≥ 100 million times
Integrated in mold tapping, in mold riveting, and in mold injection molding to reduce post-processing
Robot+visual feeding, automatic roll change, utilization rate ≥ 85%
Online detection: visual size+pressure curve+leak detection, defect rate ≤ 50 PPM

6、 Quality and traceability

IATF 16949 Automotive Stamping System
ISO 9013 Punching Accuracy Standard
Each batch: First piece full-size+10% inspection+Last piece comparison, data automatically uploaded to MES
QR code+visual engraving: mold number+roll number+operator, scan the code to trace back to the raw material furnace number
